Product Details:
Payment & Shipping Terms:
|
| Product Type: | PVC Electrical Tape | Thickness: | 0.13 Mm ±10% |
|---|---|---|---|
| Tensile: | 150 N/10 Mm Per Mm Thickness | Elongation: | 200% |
| Steel Peel: | 1.6 N/10 Mm | Voltage: | 600 V |
| Dielectric: | 40 KV/mm | Insulation: | 10⁵ MΩ |
| Flammability: | Self-extinguishing | Standards: | IS 7809 (Part 3/Sec 1): 1986, RoHS 3.0 Compliant |
| Back Peel: | 1.3 N/10 Mm | Application: | Insulating Low Voltage Splices, Joints And Terminations |
3M Temflex 150 | 0.13 mm PVC Vinyl | 600 V Rated | Self-Extinguishing | Six Colors
Product Description
3M Temflex 150 is a general use grade vinyl electrical insulating tape, 600 V rated and nominally 0.13 mm thick. An elastic PVC film carries a non-corrosive rubber-based pressure sensitive adhesive on one side. It is flame retardant and self-extinguishing, comes in six colors for circuit identification, and is aimed at residential, commercial and OEM wire work.
Structure
| Component | Material / Construction |
| Backing | elastic vinyl (PVC) film |
| Adhesive | non-corrosive rubber-based pressure sensitive |
| Release Liner | none – self-wound roll |
Datasheet
| Property | Value |
| Total thickness | 0.13 mm ±10% |
| Adhesion to steel | 1.6 N/10 mm |
| Adhesion to backing | 1.3 N/10 mm |
| Tensile strength | 150 N/10 mm per mm thickness |
| Elongation at break | 200% |
| Dielectric strength | 40 kV/mm |
| Dielectric strength after humid conditioning | 35 kV/mm |
| Insulation resistance | 10⁵ MΩ |
| Flammability | self-extinguishing |
| Maximum operating temperature | 80 °C |
| Voltage rating | 600 V |
| Standards | IS 7809 (Part 3/Sec 1): 1986, RoHS 3.0 compliant |
