Product Details:
Payment & Shipping Terms:
|
| Product Type: | Two-Part Epoxy | Color: | Off-white Base And Hardener |
|---|---|---|---|
| Shelf Life: | 12 Months | Viscosity: | 70 Pa·s |
| Mix Ratio: | 2:1 | Work Life: | 12 Minutes |
| Consistency: | Low Sagging Paste | Application: | Structural Bonding Of Aluminium And Steel |
3M Scotch-Weld DP410 | Toughened Two-Part Epoxy | 2:1 by Volume | 12 min Work Life | Off-White
Product Description
3M Scotch-Weld Epoxy Adhesive DP410 is a two part toughened epoxy structural adhesive for joints that need strength in a hurry. Mixed 2:1 by volume it becomes a low flow paste that stays where it is placed, gels within about twelve minutes at room temperature and builds strength very fast. Mild heat shortens the schedule further, and the cured bond keeps its grip at elevated temperature and in harsh environments.
Structure
| Component | Material / Construction |
| Backing | none – two-part adhesive supplied in Duo-Pak cartridges |
| Adhesive | toughened epoxy base with modified amine hardener, off-white |
| Release Liner | none – bulk adhesive |
Datasheet
| Property | Value |
| Mix ratio by volume | 2:1 |
| Mix ratio by weight | 100:47 to 100:50 |
| Color | off-white base and hardener |
| Consistency | low sagging paste |
| Base specific gravity | 1.14 |
| Hardener specific gravity | 1.07 |
| Base viscosity | 70 Pa·s (ISO 2555) |
| Work life at 23 °C | 12 minutes (ISO 10364) |
| Overlap shear on etched 2024 T3 aluminium | 34 MPa at 23 °C, 28.9 MPa at -55 °C, 8.4 MPa at 80 °C, 3.0 MPa at 100 °C, 2.0 MPa at 120 °C (EN 2243-1) |
| Shelf life | 12 months |
Features
Applications
