Product Details:
Payment & Shipping Terms:
|
| Product Type: | Acrylic Foam Tape | Thickness: | 0.4 Mm (16 Mil) |
|---|---|---|---|
| Tensile: | 550 KPa On Aluminium | Peel Adhes: | 21 N/cm To Stainless Steel After 72 H |
| Density: | 690 Kg/m³ | Liner Thk: | 0.1 Mm |
| LT Temp: | 121 °C | ST Temp: | 149 °C |
| Shear: | 1000 G At 22 °C, 500 G At 66 °C | App Temp: | 10 °C |
| Application: | Attaching Trim And Panels To Powder Coated Surfaces |
3M VHB 5915P | 0.4 mm Black Acrylic Foam | Modified Acrylic | PCK Paper Liner | 149 °C Short Term
Product Description
3M VHB Tape 5915P is a black double sided acrylic foam tape only 0.4 mm thick and a member of the 5952 family. Modified acrylic adhesive on both faces holds high, medium and medium-low surface energy substrates, powder coated paint among them. The very conformable foam fills slight mismatch between parts, so thin and dissimilar materials can be joined without rivets, welds or screws.
Structure
| Component | Material / Construction |
| Backing | very conformable acrylic foam core, black, 0.4 mm |
| Adhesive | modified acrylic on both faces |
| Release Liner | white printed PCK paper, 0.1 mm |
Datasheet
| Property | Value |
| Total tape thickness | 0.4 mm (16 mil) (ASTM D3652) |
| Thickness tolerance | ±15% |
| Foam density | 690 kg/m³ (ASTM D3574) |
| 90° peel adhesion | 21 N/cm to stainless steel after 72 h (ASTM D3330) |
| Overlap shear strength | 620 kPa on stainless steel (ASTM D1002 / ISO 4587) |
| Normal tensile | 550 kPa on aluminium (ASTM D897) |
| Static shear | 1000 g at 22 °C, 500 g at 66 °C, 250 g at 93 °C and 121 °C (ASTM D3654) |
| Long term temperature resistance | 121 °C |
| Short term temperature resistance | 149 °C |
| Minimum application temperature | 10 °C |
| Liner thickness | 0.1 mm |
