| Product Type: | Acrylic Foam Tape | Thickness: | 1.20 Mm ±0.13 Mm (0.047 In ±0.005 In) |
|---|---|---|---|
| Temp Range: | Up To 95 °C (203 °F) | Density: | 689 Kg/m³ ±64 Kg/m³ |
| Width: | 4 Mm | Core Color: | Black |
| Liner: | Red Branded Polyolefin | OEM Spec: | MS-CC260, WSS-M3G168B, GMW15201 Type XI |
| Shelf Life: | 2 Years At 4 °C To 38 °C | Application: | Primary And Secondary Door Seals |
3M Acrylic Plus ST1200 | Black 1.2 mm Foam | Heat-Activated EPDM Face | 95 °C | Weatherstrip
Product Description
3M Acrylic Plus Tape ST1200 is a black acrylic foam tape 1.2 mm thick that fixes weatherstrip and gasket seals to automotive bodies and industrial assemblies. One face is heat activated and bonds to EPDM, TPE and Santoprene TPV the moment it is pressed down, with no primer required. The other face carries pressure sensitive acrylic for rigid clear coat paint, and the soft viscoelastic core wets out against the seal to keep it tight.
Structure
| Component | Material / Construction |
| Backing | soft viscoelastic acrylic foam core, black, 1.2 mm |
| Adhesive | heat activated adhesive on the non-liner side, VR2 pressure sensitive acrylic on the liner side |
| Release Liner | red 3M branded polyolefin film, silicone coated one side |
Datasheet
| Property | Value |
| Total thickness | 1.20 mm ±0.13 mm (0.047 in ±0.005 in) |
| Foam density | 689 kg/m³ ±64 kg/m³ |
| Core color | black |
| Temperature resistance | up to 95 °C (203 °F) |
| Liner | red branded polyolefin |
| Minimum planetary roll width | 4 mm |
| Shelf life | 2 years at 4 °C to 38 °C |
| OEM specifications | MS-CC260, WSS-M3G168B, GMW15201 Type XI |
Features
Applications
