|Name:||Charge-Collection Solar Tape||Application:||Solar Panel Fabrication|
|Temperature:||320°F (160°C)||Adhesive:||0.9 Mil (0.023 Mm) Acrylic|
|Backing Thickness:||1.4 Mil (0.035 Mm)Tin-Plated Copper|
3M 3007 Charge-Collection Solar Tape Tin Plated Copper Foil Tape for Solar Panel Fabrication
3M Charge-Collection Solar Tapes are made from tin-plated copper foil with acrylic-based, pressure sensitive adhesives used in thin film solar applications requiring z-axis conductivity. These tapes can be applied at high speeds using automation equipment.
Since there is no curing required (as with liquid conductive adhesives) they allow for high productivity during panel manufacturing. The 3M Bus Tape (1007N) is not z-axis conductive and it is used as a bus tape for routing charge in thin film panels.
3M 3007 Charge-Collection Solar Tape consists of a 1-ounce tin-plated deadsoft copper foil backing and an electrically conductive pressure- sensitive adhesive. This single-coated foil tape.
|Tin-Plated Copper 1.4 mil (0.035 mm)|
|Conductive Acrylic Adhesive 0.9 mil (0.023 mm)|
|PET Release Liner 1.3 mil (0.050 mm)|
3M Charge-Collection Solar Tape 3007 is designed for use as a charge collector or bus within a thin- film solar panel. The adhesive was formulated to undergo the vacuum lamination process typically used in the manufacture of solar panels.
|Conductive Adhesive||0.9 mil (0.023 mm) Acrylic|
|Backing Thickness||1.4 mil (0.035 mm)Tin-Plated Copper|
|Total Thickness (Backing and Adhesive)||2.3 mil (0.058 mm)|
|Release Liner||1.3 mil (0.050 mm) 1-side si-coated PET|
Temperature Process (short term
|Adhesion to Steel1||1.61 lb/in (0.28 N/mm)|
|Liner Release||11 g/in|
|Breaking Strength1||34 lb/in (60 N/cm)|
Electrical Resistance Through
1 Test Method ASTM D-1000
2 Mil-Std 202 Method 307 (5 psi over 1 in2 surface area).
3 UL510 Flammability
To obtain best performance, use this product within 24 months from date of manufacture.
Store under normal conditions of 50°F to 80°F(10°C to 27°C) and less than 75% relative humidity in the original carton.
